泰仕TES-1500数字式电容表|TES1500电容表
主页 »
其它仪表 » 泰仕TES-1500数字式电容表|TES1500电容表
TES-1500
精确度 0.5%
过载保险丝保护
使用测棒或直接插入测试均可
| 檔位 |
分辨率 |
准确 |
最大显示值 |
测试频率 |
过载保护 |
|
200pF
|
0.1pF
|
±(0.5%+1+0.5pF)
|
199.9pF
|
800Hz
|
0.25A/250 Fuse Protection
|
|
2nF
|
1pF
|
±(0.5%+1)
|
1.999nF
|
800Hz
|
0.25A/250 Fuse Protection
|
|
20nF
|
10pF
|
±(0.5%+1)
|
19.99nF
|
800Hz
|
0.25A/250 Fuse Protection
|
|
200nF
|
100pF
|
± 0.5%+1)
|
199.9nF
|
800Hz
|
0.25A/250 Fuse Protection
|
|
2μF
|
1nF
|
± (0.5%+1)
|
1.999μF
|
800Hz
|
0.25A/250 Fuse Protection
|
|
20μF
|
10nF
|
± (0.5%+1)
|
19.99μF
|
80Hz
|
0.25A/250 Fuse Protection
|
|
200μF
|
100nF
|
± (0.5%+1)
|
199.9μF
|
8Hz
|
0.25A/250 Fuse Protection
|
|
2000μF
|
1μF
|
± (1%+1)
|
1999μF
|
8Hz
|
0.25A/250 Fuse Protection
|
|
20mF (20000μF)
|
10μF
|
± (2%+1)
|
19.99mF
|
8Hz
|
0.25A/250 Fuse Protection
|
|
| 取样原理 |
(双斜坡积分式) Dual Slop Integration |
| 取样率 |
Approx. 2 times per second |
| 归零调整 |
+ – 20pF Approx. |
| 操作及储存温湿度 |
0℃ to 40℃ ＜ 80% R.H.
-10℃ to 60℃ ＜ 70% R.H. |
| 电源 |
006P DC 9V 1pc |
| 尺寸 |
135mm(L) x 72mm(W) x 33mm(H) |
| 重量 |
207g |
| 附件
|
测试棒,电池,使用说明书 |
|
pF = 10-12F, nF = 10-9F,mF= 10-6F
测试电压 = 4.5V max.
输入保护:
The capacitance meter is protected by a 0.25A/250V fast blow type fuse to avoid damage |
